1. Why is this topic in the news?
On 10 September 2026, the Indian Space Research Organisation announced the successful flight-acceptance hot testing of the CE20 cryogenic engine identified for the seventh operational mission of the LVM3 launch vehicle, designated LVM3-M7.2. When was the test conducted?
The actual hot test was conducted on 9 September 2026.3. Where was the test conducted?
The test was conducted at the Main Engine & Stage Test Facility at the ISRO Propulsion Complex, Mahendragiri.4. What is IPRC?
IPRC stands for ISRO Propulsion Complex. It is a major ISRO centre associated with propulsion systems and testing of rocket stages and engines.5. Location of IPRC
The ISRO Propulsion Complex is located at Mahendragiri in Tamil Nadu. Its location is important from the UPSC Prelims perspective because space centres are frequently matched with their functions and states.6. What was being tested?
ISRO tested the CE20 cryogenic engine intended for the LVM3-M7 mission.7. What is CE20?
CE20 is an indigenous cryogenic rocket engine developed by ISRO. It powers the cryogenic upper stage of the LVM3 launch vehicle.8. Why is CE20 important?
The CE20 is among the most important propulsion technologies developed by India's space programme because cryogenic upper-stage technology is crucial for launching heavy payloads into high-energy orbits.9. What is LVM3?
LVM3 is India's heavy-lift launch vehicle. It was earlier widely known as GSLV Mk III.10. Full form of LVM
LVM stands for Launch Vehicle Mark.11. Earlier name of LVM3
LVM3 was earlier called the Geosynchronous Satellite Launch Vehicle Mark III or GSLV Mk III.12. Why was the name changed?
The name LVM3 reflects the vehicle's broader launch capability rather than associating it exclusively with geosynchronous satellite missions.13. LVM3-M7
LVM3-M7 refers to the seventh operational mission of the LVM3 launch vehicle.14. Scheduled launch period
According to ISRO's September 2026 announcement, the LVM3-M7 mission is scheduled during the fourth quarter of 2026.15. What is flight-acceptance testing?
Before an engine is integrated into a launch vehicle for flight, it must be tested to demonstrate that its systems perform according to prescribed parameters. Such testing helps establish its readiness for the mission.16. Hot testing
A hot test involves actually firing the rocket engine under controlled conditions while measuring parameters such as thrust, pressure, temperature, combustion stability and subsystem performance.17. Why are cryogenic engines hot-tested?
ISRO subjects cryogenic engines intended for missions to hot testing as part of their flight-acceptance process.18. Result of the September 2026 test
The performance of the CE20 engine met the test objectives, confirming satisfactory performance of its systems.19. Important new feature: 22-tonne thrust
The flight-acceptance test was conducted at an uprated thrust level of 22 tonnes.20. Why increase CE20 thrust?
ISRO plans to operate future LVM3 missions with a higher CE20 thrust level to enhance the payload capability of the launch vehicle.21. Payload capability
Increasing the performance of the propulsion system can allow a launch vehicle to inject greater payload mass into a desired orbit or improve mission flexibility.22. C32 stage
Future LVM3 missions are planned with the C32 cryogenic stage operating with the CE20 engine at the uprated 22-tonne thrust level.23. Meaning of cryogenic
The term cryogenic refers to extremely low temperatures. Cryogenic propulsion uses propellants that must be stored at very low temperatures to remain in liquid form.24. CE20 propellants
The CE20 uses liquid hydrogen as fuel and liquid oxygen as oxidiser.25. Liquid Hydrogen
Liquid hydrogen is commonly abbreviated as LH2. Hydrogen must be cooled to extremely low temperatures to remain liquid.26. Liquid Oxygen
Liquid oxygen is commonly abbreviated as LOX. It functions as the oxidiser in many cryogenic rocket engines.27. Why does a rocket carry an oxidiser?
A rocket cannot depend on atmospheric oxygen because much of its flight occurs where the atmosphere is extremely thin or absent. Therefore, it carries both fuel and oxidiser.28. Combustion in CE20
Hydrogen reacts with oxygen inside the propulsion system, producing high-temperature gases that are accelerated through the nozzle to generate thrust.29. Cryogenic does not mean cold exhaust
The propellants are stored at extremely low temperatures, but combustion produces extremely hot gases. The word cryogenic describes the storage condition of the propellants, not the exhaust temperature.30. Why use hydrogen?
Hydrogen-oxygen propulsion can provide very high specific impulse, making it highly efficient for upper-stage applications.31. What is specific impulse?
Specific impulse is an important measure of rocket-engine efficiency. Broadly, a higher specific impulse means the engine can produce more useful impulse for a given quantity of propellant.32. Why are cryogenic engines useful as upper stages?
Upper stages benefit greatly from high-efficiency propulsion because they operate after the vehicle has already gained substantial altitude and velocity and must provide the final energy required to reach the desired orbit.33. Challenge of liquid hydrogen
Liquid hydrogen has very low density and requires extremely low storage temperatures. This creates significant engineering challenges related to insulation, tank volume, plumbing and handling.34. Challenge of LOX
Liquid oxygen also requires cryogenic storage and careful management to prevent excessive heat transfer, evaporation and operational hazards.35. Thermal insulation
Cryogenic tanks and pipelines require specialised insulation because heat leaking from the surroundings can cause propellants to boil.36. Turbopumps
High-performance rocket engines use turbopumps to deliver propellants into the combustion chamber at the required pressure and flow rate.37. Why are turbopumps technologically challenging?
They must rotate at very high speeds while handling extremely cold fluids and operating under demanding pressure and temperature conditions.38. Combustion chamber
The combustion chamber is the region where fuel and oxidiser react to generate high-temperature and high-pressure gases.39. Rocket nozzle
The nozzle converts the thermal and pressure energy of combustion gases into high-speed exhaust, generating thrust.40. Newton's Third Law
Rocket propulsion illustrates Newton's Third Law of Motion. Expelling gases at high velocity in one direction produces a reaction force that accelerates the rocket in the opposite direction.41. Why can rockets work in space?
Rockets do not need to push against atmospheric air. Their propulsion results from conservation of momentum as exhaust gases are expelled.42. Cryogenic engine and jet engine are different
A conventional air-breathing jet engine takes oxygen from the atmosphere, whereas a rocket engine carries its oxidiser onboard.43. Nozzle designed for high altitude
The CE20 nozzle is designed for high-altitude operation, where ambient pressure is much lower than at sea level.44. Testing challenge
Testing such an engine at sea-level conditions creates difficulties because the nozzle is optimised for a very different pressure environment.45. Nozzle Protection System
ISRO developed a Nozzle Protection System, abbreviated NPS, to support testing of the high-altitude engine under sea-level test conditions.46. Purpose of NPS
The NPS helps protect and enable operation of the high-area-ratio nozzle during ground testing.47. Validation of NPS
The system had previously been validated through multiple qualification tests before being used in the flight-acceptance testing framework.48. Benefit of NPS
The Nozzle Protection System has reduced the time and effort associated with flight-acceptance testing of cryogenic engines.49. High Altitude Test Facility
Rocket-engine testing may require facilities capable of simulating low-pressure conditions corresponding to high-altitude operation.50. Why simulate altitude?
The behaviour of a rocket nozzle depends partly on ambient pressure. Therefore, engines intended for upper-stage operation need testing arrangements that appropriately account for high-altitude conditions.51. LTPM
Another important development demonstrated during the September 2026 test was the LOX Tank Pressurization Module, abbreviated LTPM.52. Full form of LTPM
LTPM stands for LOX Tank Pressurization Module.53. Connection with Gaganyaan
The LTPM demonstrated during the test is meant for C32 stages associated with Gaganyaan requirements.54. Why pressurise propellant tanks?
Maintaining appropriate tank pressure is essential for stable propellant delivery and structural and operational performance during a rocket mission.55. What happens after testing?
According to ISRO, the tested engine will be refurbished and assembled with the C32 flight stage for the LVM3-M7 mission.56. Refurbishment does not imply test failure
A rocket engine undergoing acceptance firing may require inspection, servicing and refurbishment before final flight integration because the test itself subjects the hardware to operating conditions.57. LVM3 architecture
LVM3 is a multistage launch vehicle that combines solid, liquid and cryogenic propulsion technologies.58. Solid propulsion
The vehicle uses large solid rocket boosters during the initial phase of flight.59. Liquid propulsion
Its core liquid stage contributes substantial thrust during ascent.60. Cryogenic propulsion
The cryogenic upper stage provides efficient propulsion during the later phase of the mission.61. Why combine different propulsion systems?
Different propulsion technologies offer different advantages in thrust, efficiency, controllability, storage and complexity. Multistage launch vehicles use these strengths at different phases of flight.62. Solid-propellant advantage
Solid motors are relatively simple and can generate high thrust, making them useful during lift-off and early ascent.63. Solid-propellant limitation
Once ignited, traditional solid motors are generally less controllable than liquid engines.64. Liquid-engine advantage
Liquid engines can generally provide greater control over propellant flow and engine operation.65. Cryogenic-engine advantage
Cryogenic hydrogen-oxygen propulsion provides high efficiency, making it especially valuable for upper stages.66. Why is upper-stage efficiency important?
At the upper stage, additional velocity is extremely valuable. High-efficiency propulsion can significantly affect payload capability.67. Staging
A multistage rocket discards stages after their propellant has been consumed, reducing dead mass and allowing the remaining vehicle to accelerate more efficiently.68. Orbital velocity
A satellite must acquire sufficient horizontal velocity to remain in orbit around Earth rather than simply reaching a high altitude.69. Orbit is continuous free fall
An orbiting satellite is continuously falling toward Earth under gravity while moving forward fast enough that Earth's curved surface falls away beneath it.70. Geostationary orbit
A satellite in a circular equatorial orbit at the appropriate altitude and moving in the same direction as Earth's rotation can appear stationary relative to a point on Earth.71. Geosynchronous and geostationary are not identical
Every geostationary orbit is geosynchronous, but a geosynchronous orbit need not necessarily be circular and equatorial. Therefore, every geosynchronous satellite is not necessarily geostationary.72. Geostationary Transfer Orbit
A Geostationary Transfer Orbit is an elliptical transfer orbit commonly used as an intermediate step for placing spacecraft into geostationary orbit.73. Why heavy launch vehicles matter
Heavy launch vehicles expand a country's ability to deploy large communication satellites, scientific spacecraft, human-spaceflight systems and other high-mass payloads.74. Strategic importance
Indigenous heavy-launch capability reduces dependence on foreign launch providers and strengthens technological autonomy.75. Commercial importance
A reliable heavy-lift vehicle can also support commercial launch services in the international space market.76. Human-spaceflight importance
LVM3 has been selected as the launch vehicle for India's Gaganyaan human-spaceflight programme.77. Human-rating
A launch system intended to carry humans requires additional reliability, redundancy, safety assessment and qualification compared with ordinary missions.78. Human Rated LVM3
The Gaganyaan programme uses a human-rated version of LVM3, often referred to as HLVM3.79. Gaganyaan objective
Gaganyaan represents India's programme to demonstrate indigenous human-spaceflight capability.80. Crew Module
The Crew Module is the part of the spacecraft designed to accommodate astronauts during the mission.81. Service Module
The Service Module supports the Crew Module with systems needed for mission operations.82. Orbital Module
In the Gaganyaan architecture, the Crew Module and Service Module together form the Orbital Module.83. Crew Escape System
A human-spaceflight launch system requires an emergency mechanism capable of moving the crew module away from a malfunctioning launch vehicle during critical phases.84. Cryogenic technology and strategic autonomy
Mastery of cryogenic propulsion is strategically significant because the technology is highly complex and directly influences heavy-launch capability.85. India's cryogenic journey
India's development of indigenous cryogenic technology was a major milestone in the evolution of its launch-vehicle programme.86. Indigenous capability
Developing propulsion technology domestically builds expertise across materials science, precision engineering, fluid mechanics, thermodynamics, combustion science and control systems.87. Materials challenge
Cryogenic systems must tolerate extreme temperature differences between stored propellants and hot combustion gases.88. Thermal contraction
Materials contract at extremely low temperatures, requiring engineers to account for dimensional changes and mechanical stresses.89. Hydrogen embrittlement
Hydrogen can interact with some materials in ways that degrade mechanical properties. Material selection is therefore an important engineering challenge.90. Sealing challenge
Preventing leakage of very cold, low-density hydrogen requires highly reliable seals, joints and plumbing systems.91. Ignition challenge
Cryogenic engines require carefully controlled ignition sequences because fuel and oxidiser flows must reach appropriate conditions for stable combustion.92. Combustion instability
Pressure oscillations inside a rocket combustion chamber can become dangerous. Engine development therefore requires detailed analysis and testing of combustion stability.93. Engine qualification
Before a new engine configuration is used operationally, it undergoes extensive qualification testing across expected operating conditions.94. Qualification test versus acceptance test
Qualification demonstrates that a design can withstand its intended operational environment. Acceptance testing checks whether a particular flight unit meets the required performance standards.95. Static firing
During a static firing test, the engine remains secured to a test stand while being operated and instrumented.96. Telemetry and sensors
Testing uses sensors to measure temperatures, pressures, vibration, flow rates, thrust and other parameters needed to evaluate engine health.97. Reliability through testing
Ground testing allows engineers to identify anomalies before flight, where failure would be far more costly and potentially dangerous.98. Payload fraction
Only a relatively small fraction of a launch vehicle's lift-off mass becomes useful payload. Improving engine efficiency and reducing structural mass can improve payload performance.99. Rocket equation
Rocket performance depends strongly on exhaust velocity and mass ratio. This explains why high-specific-impulse propulsion and multistaging are important.100. Why not use cryogenic propulsion at every stage?
Cryogenic propulsion is efficient but technically complex, requires bulky insulated tanks and extremely low-temperature handling. Other propulsion systems may be more suitable where very high initial thrust, simplicity or storage characteristics are more important.101. Cryogenic versus semi-cryogenic propulsion
Cryogenic propulsion commonly uses liquid hydrogen and liquid oxygen, whereas semi-cryogenic propulsion generally uses a hydrocarbon fuel such as refined kerosene with liquid oxygen.102. Why semi-cryogenic technology matters
Semi-cryogenic systems can offer high density and strong thrust performance and are therefore attractive for booster or core-stage applications.103. Cryogenic versus hypergolic propellants
Hypergolic propellants ignite spontaneously when fuel and oxidiser come into contact, whereas cryogenic propellants require very low-temperature storage and controlled ignition.104. Advantage of hypergolic propellants
They are useful where reliable ignition and restart capability are important.105. Limitation of many hypergolic propellants
Several commonly used hypergolic propellants are highly toxic and environmentally hazardous.106. Propellant density matters
Low-density fuels require larger tanks for the same mass of propellant, affecting vehicle dimensions and structural design.107. Hydrogen's special challenge
Liquid hydrogen offers excellent specific impulse but has very low density, which requires comparatively large tanks.108. Boil-off
Heat entering a cryogenic tank can cause liquid propellant to vaporise. This phenomenon is called boil-off.109. Tank pressurisation
Pressurisation systems help maintain tank conditions necessary for structural stability and controlled propellant delivery.110. Importance of LTPM demonstration
The successful demonstration of the LOX Tank Pressurization Module during the CE20 test is significant because propulsion reliability depends not only on the main engine but also on associated fluid and pressurisation systems.111. System engineering
Launch-vehicle success depends on integration of propulsion, structures, avionics, navigation, guidance, thermal protection, telemetry and ground systems.112. Avionics
Avionics include electronic systems used for navigation, guidance, control, telemetry and vehicle management.113. Guidance system
The guidance system determines the required trajectory and commands necessary to place the payload into the intended orbit.114. Navigation system
Navigation systems estimate the vehicle's position, velocity and orientation during flight.115. Control system
The control system ensures that the launch vehicle follows the required orientation and trajectory.116. Thrust-vector control
Changing the direction of engine thrust can be used to control a rocket's attitude and trajectory.117. Payload fairing
A payload fairing protects the spacecraft from aerodynamic forces and heating during atmospheric ascent.118. Fairing separation
Once the vehicle reaches sufficiently thin atmosphere, the fairing can be discarded because its protective function is no longer required.119. Space debris consideration
Modern launch systems increasingly need to consider responsible disposal of spent stages and orbital debris mitigation.120. Sustainable space operations
As launch frequency increases globally, long-term sustainability of outer space is becoming an important policy and technological issue.121. Space situational awareness
Space situational awareness involves tracking objects and understanding conditions in the space environment to reduce collision and operational risks.122. India's broader space ecosystem
India's space sector increasingly includes ISRO, NewSpace India Limited, IN-SPACe, private companies, startups and academic institutions.123. Role of ISRO
ISRO is India's national space agency and operates under the Department of Space.124. Department of Space
The Department of Space is responsible for India's national space programme and works through institutions including ISRO and related organisations.125. IN-SPACe
The Indian National Space Promotion and Authorization Centre facilitates and authorises participation of non-government entities in India's space sector.126. NSIL
NewSpace India Limited is a Central Public Sector Enterprise under the Department of Space and plays an important role in commercialising space-based capabilities and services.127. Space technology and economy
Launch capability supports communication, navigation, Earth observation, meteorology, disaster management, national security, scientific exploration and commercial services.128. Earth observation
Satellite data can support agriculture, forestry, water-resource management, urban planning, disaster assessment and environmental monitoring.129. Communication satellites
Communication satellites enable services including broadcasting, telecommunications and connectivity.130. Navigation satellites
Satellite navigation supports positioning, navigation and timing services used in transport, communication, mapping and many economic sectors.131. Space and disaster management
Remote-sensing satellites can provide information on cyclones, floods, forest fires, landslides and other hazards.132. Space and national development
India's space programme has traditionally emphasised the use of space technology for socioeconomic development in addition to scientific and strategic objectives.133. Why CE20 matters beyond one mission
The September 2026 test is not merely an isolated engine event. It represents continuing efforts to improve LVM3 performance and strengthen India's heavy-launch capability.134. Uprating an engine
Uprating involves operating or modifying an engine to achieve higher performance while ensuring that thermal, structural and combustion margins remain acceptable.135. Why higher thrust requires testing
Increasing thrust changes pressures, temperatures, flow rates and mechanical loads. Extensive testing is therefore necessary before operational use.136. 22-tonne test significance
The September 2026 acceptance test demonstrated the CE20 flight engine at the planned uprated 22-tonne thrust level.137. Mission-specific engine
The tested CE20 engine has been identified for the LVM3-M7 mission rather than being merely a generic experimental engine.138. Test-to-flight pathway
After successful testing, the engine is refurbished, integrated into the flight stage, subjected to further checks and prepared for launch integration.139. Prelims trap: CE20 is not a solid motor
CE20 is a liquid-propellant cryogenic engine. It should not be confused with LVM3's large solid boosters.140. Prelims trap: CE20 is not air-breathing
CE20 carries both its fuel and oxidiser. It does not obtain oxygen from the atmosphere like an air-breathing jet engine.141. Prelims trap: LOX is the oxidiser
In the CE20 propulsion combination, liquid hydrogen is the fuel and liquid oxygen is the oxidiser.142. Prelims trap: cryogenic does not mean low-temperature combustion
Cryogenic refers to propellant storage at extremely low temperature. The combustion gases themselves reach very high temperatures.143. Prelims trap: geostationary versus geosynchronous
A geostationary satellite must be in a circular equatorial geosynchronous orbit and appear fixed relative to Earth. Not every geosynchronous orbit satisfies these conditions.144. Prelims trap: rocket propulsion does not require atmospheric air
A rocket operates in vacuum because it carries its own oxidiser and generates thrust through momentum exchange.145. Prelims trap: IPRC location
The ISRO Propulsion Complex associated with the CE20 test is at Mahendragiri, Tamil Nadu.146. Prelims trap: LVM3's earlier name
LVM3 was earlier known as GSLV Mk III.147. Prelims trap: mission number
LVM3-M7 is described by ISRO as the seventh operational mission of LVM3.148. Prelims trap: test date and announcement date
The hot test was conducted on 9 September 2026, while ISRO published the update on 10 September 2026.149. Prelims trap: scheduled mission period
ISRO stated that LVM3-M7 is scheduled during the fourth quarter of 2026.150. Prelims trap: NPS
NPS in this context means Nozzle Protection System, not a navigation or satellite system.151. Prelims trap: LTPM
LTPM stands for LOX Tank Pressurization Module.152. Prelims trap: C32
C32 refers to the cryogenic stage configuration associated with the CE20 engine in the future LVM3 architecture discussed by ISRO.153. Why this matters for UPSC
The topic combines current affairs with static concepts including cryogenic propulsion, rocket stages, orbital mechanics, ISRO institutions, Gaganyaan and India's space-sector architecture.154. Potential Prelims area
UPSC can ask matching questions involving CE20, LOX, LH2, LVM3, IPRC, cryogenic propulsion and Gaganyaan.155. Potential statement-based question
Statements may test whether CE20 uses atmospheric oxygen, whether liquid hydrogen is the oxidiser, or whether cryogenic propulsion is mainly associated with the upper stage.156. Potential conceptual question
UPSC may ask why cryogenic propulsion is attractive for upper stages. The key idea is high efficiency or specific impulse.157. Potential location question
Candidates should remember Mahendragiri in Tamil Nadu in connection with ISRO propulsion testing.158. Potential Gaganyaan linkage
The CE20/C32 ecosystem is relevant to the human-rated LVM3 architecture supporting India's Gaganyaan programme.159. Potential physics linkage
Rocket propulsion is based fundamentally on conservation of momentum and can also be explained through Newton's Third Law.160. Potential engineering linkage
Cryogenic technology requires mastery of extremely low-temperature storage, turbomachinery, combustion, materials, insulation and precision control.161. Potential strategic linkage
Indigenous propulsion capability supports technological sovereignty and reduces dependence on external suppliers for critical launch technologies.162. Potential economic linkage
Improved payload capability can strengthen India's ability to compete in commercial launch markets and support larger domestic spacecraft.163. Potential science-policy linkage
Investment in advanced propulsion produces technological spillovers in materials, manufacturing, testing, computational engineering and control systems.164. Quick Revision 1
CE20 is ISRO's indigenous cryogenic engine used for the LVM3 upper stage.165. Quick Revision 2
CE20 uses liquid hydrogen as fuel and liquid oxygen as oxidiser.166. Quick Revision 3
The latest flight-acceptance hot test was conducted on 9 September 2026.167. Quick Revision 4
The test was conducted at IPRC, Mahendragiri, Tamil Nadu.168. Quick Revision 5
The tested CE20 engine is intended for the LVM3-M7 mission.169. Quick Revision 6
LVM3-M7 is the seventh operational mission of LVM3.170. Quick Revision 7
The CE20 engine was tested at an uprated thrust level of 22 tonnes.171. Quick Revision 8
Future LVM3 missions are planned with the C32 stage operating with CE20 at the higher thrust level.172. Quick Revision 9
NPS stands for Nozzle Protection System.173. Quick Revision 10
LTPM stands for LOX Tank Pressurization Module.174. Quick Revision 11
The LTPM demonstrated during the test is associated with C32 stages for Gaganyaan requirements.175. Quick Revision 12
ISRO stated that the LVM3-M7 mission is scheduled during the fourth quarter of 2026.176. Conclusion
The successful CE20 flight-acceptance test demonstrates the continuing maturation of India's indigenous cryogenic propulsion capability. More importantly, testing the engine at an uprated 22-tonne thrust level points toward improved payload performance for future LVM3 missions. Combined with developments in the C32 stage, Gaganyaan-related systems and advanced ground-testing technologies, the CE20 programme is central to India's ambitions in heavy launch, human spaceflight, commercial space services and strategic technological autonomy.हिन्दी
1. यह विषय चर्चा में क्यों है?
10 सितंबर 2026 को भारतीय अंतरिक्ष अनुसंधान संगठन ने LVM3 प्रक्षेपण यान के सातवें परिचालन मिशन LVM3-M7 के लिए निर्धारित CE20 क्रायोजेनिक इंजन के सफल उड़ान-स्वीकृति उष्ण परीक्षण की घोषणा की।2. परीक्षण कब किया गया?
वास्तविक परीक्षण 9 सितंबर 2026 को किया गया था।3. परीक्षण कहाँ हुआ?
यह परीक्षण इसरो प्रणोदन परिसर, महेंद्रगिरि स्थित मुख्य इंजन एवं चरण परीक्षण सुविधा में किया गया।4. IPRC क्या है?
IPRC का पूर्ण रूप ISRO Propulsion Complex है। यह इसरो का प्रमुख केंद्र है जो रॉकेट प्रणोदन प्रणालियों और इंजन परीक्षण से संबंधित है।5. IPRC कहाँ स्थित है?
इसरो प्रणोदन परिसर तमिलनाडु के महेंद्रगिरि में स्थित है। प्रारंभिक परीक्षा में इसरो केंद्रों और उनके स्थानों का मिलान पूछा जा सकता है।6. किस इंजन का परीक्षण किया गया?
LVM3-M7 मिशन के लिए निर्धारित CE20 क्रायोजेनिक इंजन का परीक्षण किया गया।7. CE20 क्या है?
CE20 इसरो द्वारा विकसित स्वदेशी क्रायोजेनिक रॉकेट इंजन है। यह LVM3 के क्रायोजेनिक ऊपरी चरण को शक्ति प्रदान करता है।8. CE20 का महत्व
क्रायोजेनिक प्रणोदन भारी उपग्रहों और उच्च ऊर्जा वाली कक्षीय आवश्यकताओं के लिए अत्यंत महत्वपूर्ण है। इसलिए CE20 भारत की प्रमुख अंतरिक्ष प्रौद्योगिकियों में से एक है।9. LVM3 क्या है?
LVM3 भारत का भारी प्रक्षेपण यान है। इसे पहले व्यापक रूप से GSLV Mk III कहा जाता था।10. LVM का पूर्ण रूप
LVM का अर्थ Launch Vehicle Mark है।11. LVM3 का पुराना नाम
LVM3 का पूर्व नाम Geosynchronous Satellite Launch Vehicle Mark III अर्थात GSLV Mk III था।12. नाम परिवर्तन का महत्व
LVM3 नाम यान की व्यापक प्रक्षेपण क्षमता को दर्शाता है और इसे केवल भू-समकालिक उपग्रह मिशनों तक सीमित नहीं करता।13. LVM3-M7 क्या है?
LVM3-M7, LVM3 प्रक्षेपण यान का सातवाँ परिचालन मिशन है।14. मिशन कब निर्धारित है?
इसरो की सितंबर 2026 की सूचना के अनुसार LVM3-M7 मिशन 2026 की चौथी तिमाही में निर्धारित है।15. उड़ान-स्वीकृति परीक्षण क्या है?
किसी इंजन को वास्तविक मिशन में लगाने से पहले यह सुनिश्चित किया जाता है कि उसकी सभी प्रणालियाँ निर्धारित मानकों के अनुसार कार्य कर रही हैं। इसी उद्देश्य से उड़ान-स्वीकृति परीक्षण किया जाता है।16. उष्ण परीक्षण क्या है?
इसमें इंजन को नियंत्रित परिस्थितियों में वास्तव में प्रज्वलित किया जाता है और प्रणोद, दबाव, तापमान, दहन स्थिरता तथा अन्य मापदंडों की जाँच की जाती है।17. क्रायोजेनिक इंजन का परीक्षण क्यों आवश्यक है?
वास्तविक उड़ान में प्रयुक्त होने वाले क्रायोजेनिक इंजन को मिशन से पहले उसकी विश्वसनीयता और प्रदर्शन की पुष्टि के लिए परीक्षण से गुजरना पड़ता है।18. सितंबर 2026 परीक्षण का परिणाम
CE20 इंजन ने निर्धारित सभी परीक्षण उद्देश्यों को पूरा किया और उसकी प्रणालियों का प्रदर्शन संतोषजनक पाया गया।19. 22 टन प्रणोद का महत्व
इस परीक्षण में CE20 इंजन को उन्नत 22 टन प्रणोद स्तर पर चलाया गया।20. प्रणोद क्यों बढ़ाया जा रहा है?
इसरो भविष्य के LVM3 मिशनों की भार वहन क्षमता बढ़ाने के लिए CE20 को अधिक प्रणोद स्तर पर संचालित करने की योजना बना रहा है।21. भार वहन क्षमता
प्रणोदन प्रणाली का प्रदर्शन बढ़ने से प्रक्षेपण यान अधिक द्रव्यमान वाले उपग्रह को निर्धारित कक्षा में पहुँचा सकता है या मिशन में अधिक लचीलापन प्राप्त कर सकता है।22. C32 चरण
भविष्य के LVM3 मिशनों में C32 क्रायोजेनिक चरण को CE20 इंजन के 22 टन उन्नत प्रणोद स्तर के साथ संचालित करने की योजना है।23. क्रायोजेनिक का अर्थ
क्रायोजेनिक शब्द अत्यंत निम्न तापमान से संबंधित है। ऐसे प्रणोदन में प्रयुक्त प्रणोदकों को द्रव अवस्था में बनाए रखने के लिए बहुत कम तापमान पर संग्रहित करना पड़ता है।24. CE20 के प्रणोदक
CE20 में द्रव हाइड्रोजन ईंधन के रूप में और द्रव ऑक्सीजन ऑक्सीकारक के रूप में प्रयुक्त होता है।25. द्रव हाइड्रोजन
द्रव हाइड्रोजन को सामान्यतः LH2 कहा जाता है। हाइड्रोजन को द्रव बनाए रखने के लिए अत्यंत निम्न तापमान की आवश्यकता होती है।26. द्रव ऑक्सीजन
द्रव ऑक्सीजन को LOX कहा जाता है। यह क्रायोजेनिक रॉकेट इंजन में ऑक्सीकारक का कार्य करता है।27. रॉकेट ऑक्सीकारक अपने साथ क्यों ले जाता है?
रॉकेट की उड़ान का बड़ा भाग ऐसे क्षेत्र में होता है जहाँ वायुमंडलीय ऑक्सीजन बहुत कम या अनुपस्थित होती है। इसलिए रॉकेट ईंधन और ऑक्सीकारक दोनों अपने साथ ले जाता है।28. CE20 में दहन
हाइड्रोजन और ऑक्सीजन की अभिक्रिया से अत्यधिक तापमान वाली गैसें बनती हैं। इन्हें नोजल से उच्च वेग से बाहर निकालकर प्रणोद उत्पन्न किया जाता है।29. क्रायोजेनिक का अर्थ ठंडा निकास नहीं है
प्रणोदक अत्यंत कम तापमान पर रखे जाते हैं, लेकिन दहन के बाद उत्पन्न गैसों का तापमान अत्यधिक होता है।30. हाइड्रोजन का उपयोग क्यों?
हाइड्रोजन और ऑक्सीजन का संयोजन उच्च विशिष्ट आवेग प्रदान कर सकता है। इस कारण यह ऊपरी चरणों के लिए अत्यंत प्रभावी है।31. विशिष्ट आवेग क्या है?
विशिष्ट आवेग रॉकेट इंजन की दक्षता का एक महत्वपूर्ण माप है। सामान्य रूप से अधिक विशिष्ट आवेग का अर्थ है कि समान मात्रा के प्रणोदक से अधिक उपयोगी आवेग प्राप्त किया जा सकता है।32. ऊपरी चरण में क्रायोजेनिक इंजन क्यों उपयोगी है?
ऊपरी चरण को उपग्रह को अंतिम आवश्यक वेग देने की आवश्यकता होती है। यहाँ उच्च दक्षता वाली प्रणोदन प्रणाली भार वहन क्षमता बढ़ाने में विशेष रूप से उपयोगी होती है।33. द्रव हाइड्रोजन की चुनौती
द्रव हाइड्रोजन का घनत्व बहुत कम होता है और इसे अत्यंत निम्न तापमान पर रखना पड़ता है। इसलिए बड़े टैंक, विशेष ऊष्मा-रोधन और जटिल पाइप व्यवस्था की आवश्यकता होती है।34. द्रव ऑक्सीजन की चुनौती
द्रव ऑक्सीजन को भी अत्यंत कम तापमान पर रखना पड़ता है। ऊष्मा प्रवेश, वाष्पीकरण और सुरक्षा का सावधानीपूर्वक प्रबंधन आवश्यक है।35. ऊष्मा-रोधन
क्रायोजेनिक टैंकों और पाइपों को विशेष ऊष्मा-रोधन की आवश्यकता होती है, क्योंकि बाहरी ऊष्मा प्रणोदक को उबाल सकती है।36. टर्बोपंप
उच्च प्रदर्शन वाले रॉकेट इंजन में टर्बोपंप प्रणोदकों को आवश्यक दबाव और प्रवाह दर पर दहन कक्ष तक पहुँचाते हैं।37. टर्बोपंप की तकनीकी कठिनाई
इन्हें अत्यधिक गति से घूमते हुए अत्यंत ठंडे द्रवों को संभालना पड़ता है। इस कारण इनका निर्माण अत्यंत जटिल होता है।38. दहन कक्ष
दहन कक्ष वह स्थान है जहाँ ईंधन और ऑक्सीकारक की अभिक्रिया से उच्च तापमान और दबाव वाली गैसें बनती हैं।39. रॉकेट नोजल
नोजल दहन गैसों की ऊष्मीय और दाब ऊर्जा को उच्च वेग वाले निकास में बदलता है, जिससे प्रणोद उत्पन्न होता है।40. न्यूटन का तीसरा नियम
रॉकेट प्रणोदन न्यूटन के तीसरे गति नियम का उत्कृष्ट उदाहरण है। गैसों को एक दिशा में उच्च वेग से बाहर निकालने पर रॉकेट विपरीत दिशा में बल प्राप्त करता है।41. रॉकेट अंतरिक्ष में कैसे चलता है?
रॉकेट को वायु को धक्का देने की आवश्यकता नहीं होती। वह अपने साथ प्रणोदक और ऑक्सीकारक लेकर चलता है और संवेग संरक्षण के सिद्धांत से प्रणोद उत्पन्न करता है।42. रॉकेट इंजन और जेट इंजन में अंतर
वायु-श्वासी जेट इंजन वातावरण से ऑक्सीजन लेता है, जबकि रॉकेट इंजन अपना ऑक्सीकारक स्वयं साथ ले जाता है।43. उच्च ऊँचाई के लिए नोजल
CE20 का नोजल उच्च ऊँचाई पर संचालन के लिए बनाया गया है, जहाँ बाहरी वायुदाब समुद्र तल की तुलना में बहुत कम होता है।44. समुद्र तल पर परीक्षण की चुनौती
उच्च ऊँचाई के लिए बनाए गए नोजल का समुद्र तल की परिस्थितियों में परीक्षण करना तकनीकी रूप से चुनौतीपूर्ण होता है।45. नोजल सुरक्षा प्रणाली
इसरो ने इस उद्देश्य से Nozzle Protection System अर्थात NPS विकसित किया है।46. NPS का उद्देश्य
यह प्रणाली भूमि पर परीक्षण के दौरान उच्च क्षेत्रफल अनुपात वाले नोजल की सुरक्षा और उचित संचालन में सहायता करती है।47. NPS का प्रमाणीकरण
इस प्रणाली को पहले कई योग्यता परीक्षणों के माध्यम से प्रमाणित किया जा चुका था।48. NPS का लाभ
इस प्रणाली ने क्रायोजेनिक इंजन के उड़ान-स्वीकृति परीक्षण में लगने वाले समय और प्रयास को कम किया है।49. उच्च ऊँचाई परीक्षण सुविधा
ऊपरी चरण के इंजन के परीक्षण के लिए ऐसी व्यवस्था की आवश्यकता हो सकती है जो कम बाहरी दाब वाली उच्च ऊँचाई की परिस्थितियों का अनुकरण कर सके।50. ऊँचाई का अनुकरण क्यों?
रॉकेट नोजल का व्यवहार बाहरी दाब से प्रभावित होता है। इसलिए उच्च ऊँचाई पर कार्य करने वाले इंजन के परीक्षण में उपयुक्त दाब परिस्थितियों का ध्यान रखना आवश्यक है।51. LTPM
सितंबर 2026 के परीक्षण में LOX Tank Pressurization Module अर्थात LTPM का भी सफल प्रदर्शन किया गया।52. LTPM का पूर्ण रूप
LTPM का अर्थ LOX Tank Pressurization Module है।53. गगनयान से संबंध
परीक्षण में प्रदर्शित LTPM, गगनयान आवश्यकताओं से संबंधित C32 चरणों के लिए निर्धारित है।54. टैंक का दाब बनाए रखना क्यों आवश्यक है?
उचित टैंक दाब प्रणोदक के नियंत्रित प्रवाह, संरचनात्मक स्थिरता और विश्वसनीय इंजन संचालन के लिए आवश्यक है।55. परीक्षण के बाद क्या होगा?
इसरो के अनुसार परीक्षण किए गए इंजन का पुनर्सज्जीकरण किया जाएगा और इसे LVM3-M7 मिशन के C32 उड़ान चरण में लगाया जाएगा।56. पुनर्सज्जीकरण का अर्थ विफलता नहीं है
स्वीकृति परीक्षण में इंजन वास्तविक परिचालन परिस्थितियों का सामना करता है। इसलिए उड़ान से पहले निरीक्षण, सेवा और आवश्यक पुनर्सज्जीकरण सामान्य प्रक्रिया का हिस्सा हो सकते हैं।57. LVM3 की संरचना
LVM3 बहु-चरणीय प्रक्षेपण यान है जिसमें ठोस, द्रव और क्रायोजेनिक प्रणोदन तकनीकों का संयोजन किया गया है।58. ठोस प्रणोदन
प्रारंभिक उड़ान के लिए LVM3 बड़े ठोस रॉकेट बूस्टरों का उपयोग करता है।59. द्रव प्रणोदन
इसका द्रव कोर चरण आरोहण के दौरान महत्वपूर्ण प्रणोद प्रदान करता है।60. क्रायोजेनिक प्रणोदन
ऊपरी क्रायोजेनिक चरण मिशन के बाद के भाग में उच्च दक्षता वाला प्रणोद प्रदान करता है।61. विभिन्न प्रणोदन प्रणालियों का संयोजन क्यों?
ठोस, द्रव और क्रायोजेनिक प्रणोदन प्रणालियों की अलग-अलग विशेषताएँ हैं। बहु-चरणीय यान उड़ान के अलग-अलग चरणों में इनका लाभ उठाता है।62. ठोस मोटर का लाभ
ठोस मोटर अपेक्षाकृत सरल होती है और बहुत अधिक प्रारंभिक प्रणोद प्रदान कर सकती है।63. ठोस मोटर की सीमा
एक बार प्रज्वलित होने के बाद पारंपरिक ठोस मोटर का नियंत्रण द्रव इंजन की तुलना में सीमित होता है।64. द्रव इंजन का लाभ
द्रव इंजन में प्रणोदक प्रवाह और इंजन संचालन पर अपेक्षाकृत अधिक नियंत्रण संभव होता है।65. क्रायोजेनिक इंजन का लाभ
हाइड्रोजन-ऑक्सीजन आधारित क्रायोजेनिक प्रणोदन उच्च दक्षता प्रदान करता है और ऊपरी चरण के लिए अत्यंत उपयोगी है।66. ऊपरी चरण की दक्षता क्यों महत्वपूर्ण है?
ऊपरी चरण में प्राप्त अतिरिक्त वेग उपग्रह की अंतिम कक्षा निर्धारित करने में महत्वपूर्ण होता है। इसलिए उच्च दक्षता भार वहन क्षमता को बढ़ा सकती है।67. चरण विभाजन
बहु-चरणीय रॉकेट प्रयुक्त चरणों को अलग कर देता है। इससे मृत भार कम होता है और शेष यान अधिक कुशलता से गति प्राप्त कर सकता है।68. कक्षीय वेग
उपग्रह को केवल ऊँचाई तक पहुँचना पर्याप्त नहीं है। उसे पृथ्वी के चारों ओर कक्षा में बने रहने के लिए पर्याप्त क्षैतिज वेग भी चाहिए।69. कक्षा निरंतर मुक्त पतन है
कक्षा में उपग्रह गुरुत्वाकर्षण के कारण लगातार पृथ्वी की ओर गिरता है, लेकिन उसकी आगे की गति इतनी अधिक होती है कि पृथ्वी की वक्र सतह उससे नीचे हटती रहती है।70. भूस्थिर कक्षा
उचित ऊँचाई पर वृत्ताकार भूमध्यरेखीय कक्षा में पृथ्वी के घूर्णन की दिशा में घूमने वाला उपग्रह पृथ्वी से स्थिर दिखाई दे सकता है।71. भू-समकालिक और भूस्थिर में अंतर
हर भूस्थिर कक्षा भू-समकालिक होती है, लेकिन हर भू-समकालिक कक्षा भूस्थिर नहीं होती। भूस्थिर होने के लिए कक्षा का वृत्ताकार और भूमध्यरेखीय होना आवश्यक है।72. भूस्थिर स्थानांतरण कक्षा
यह एक दीर्घवृत्ताकार स्थानांतरण कक्षा है जिसका उपयोग अंतरिक्ष यान को भूस्थिर कक्षा की दिशा में भेजने के मध्यवर्ती चरण के रूप में किया जाता है।73. भारी प्रक्षेपण यान का महत्व
ऐसे यान बड़े संचार उपग्रह, वैज्ञानिक अंतरिक्ष यान, मानव अंतरिक्ष उड़ान प्रणाली और अन्य भारी पेलोड भेजने की क्षमता बढ़ाते हैं।74. रणनीतिक महत्व
स्वदेशी भारी प्रक्षेपण क्षमता विदेशी प्रक्षेपण सेवाओं पर निर्भरता कम करती है और तकनीकी आत्मनिर्भरता मजबूत करती है।75. वाणिज्यिक महत्व
विश्वसनीय भारी प्रक्षेपण यान अंतरराष्ट्रीय वाणिज्यिक प्रक्षेपण बाजार में भारत की भूमिका बढ़ा सकता है।76. मानव अंतरिक्ष उड़ान में महत्व
भारत के गगनयान मानव अंतरिक्ष उड़ान कार्यक्रम के लिए LVM3 को आधार प्रक्षेपण यान के रूप में चुना गया है।77. मानव-अनुकूलन
मानव को अंतरिक्ष में ले जाने वाले प्रक्षेपण यान में सामान्य मिशनों की तुलना में अधिक विश्वसनीयता, अतिरिक्त सुरक्षा, पुनरावृत्ति और कठोर प्रमाणीकरण आवश्यक होता है।78. मानव-अनुकूलित LVM3
गगनयान में LVM3 के मानव-अनुकूलित संस्करण का उपयोग किया जाता है, जिसे HLVM3 भी कहा जाता है।79. गगनयान का उद्देश्य
गगनयान भारत की स्वदेशी मानव अंतरिक्ष उड़ान क्षमता प्रदर्शित करने का कार्यक्रम है।80. क्रू मॉड्यूल
क्रू मॉड्यूल अंतरिक्ष यान का वह भाग है जिसमें अंतरिक्ष यात्री मिशन के दौरान रहते हैं।81. सर्विस मॉड्यूल
सर्विस मॉड्यूल मिशन संचालन के लिए आवश्यक सहायक प्रणालियाँ प्रदान करता है।82. ऑर्बिटल मॉड्यूल
गगनयान संरचना में क्रू मॉड्यूल और सर्विस मॉड्यूल मिलकर ऑर्बिटल मॉड्यूल बनाते हैं।83. क्रू एस्केप सिस्टम
आपात स्थिति में चालक दल को खराब हो रहे प्रक्षेपण यान से शीघ्र दूर ले जाने के लिए विशेष बचाव प्रणाली आवश्यक होती है।84. क्रायोजेनिक तकनीक और रणनीतिक स्वायत्तता
क्रायोजेनिक प्रणोदन अत्यंत जटिल तकनीक है। इसमें स्वदेशी क्षमता भारी प्रक्षेपण और रणनीतिक तकनीकी स्वायत्तता के लिए महत्वपूर्ण है।85. भारत की क्रायोजेनिक यात्रा
स्वदेशी क्रायोजेनिक तकनीक का विकास भारत के प्रक्षेपण यान कार्यक्रम के विकास में एक प्रमुख उपलब्धि रहा है।86. स्वदेशी क्षमता का व्यापक लाभ
ऐसी तकनीक पदार्थ विज्ञान, सटीक अभियांत्रिकी, द्रव यांत्रिकी, ऊष्मागतिकी, दहन विज्ञान और नियंत्रण प्रणालियों में विशेषज्ञता विकसित करती है।87. पदार्थ संबंधी चुनौती
क्रायोजेनिक प्रणाली को अत्यंत ठंडे प्रणोदकों और अत्यधिक गर्म दहन गैसों के बीच विशाल तापमान अंतर सहना पड़ता है।88. तापीय संकुचन
अत्यंत कम तापमान पर पदार्थ सिकुड़ते हैं। इसलिए आयाम परिवर्तन और यांत्रिक तनाव का विशेष ध्यान रखना पड़ता है।89. हाइड्रोजन भंगुरता
हाइड्रोजन कुछ पदार्थों के यांत्रिक गुणों को प्रभावित कर सकता है। इसलिए उपयुक्त पदार्थ का चयन अत्यंत महत्वपूर्ण है।90. सीलिंग की चुनौती
बहुत ठंडे और कम घनत्व वाले हाइड्रोजन का रिसाव रोकने के लिए अत्यंत विश्वसनीय सील, जोड़ और पाइप प्रणाली आवश्यक है।91. प्रज्वलन की चुनौती
स्थिर दहन प्राप्त करने के लिए ईंधन और ऑक्सीकारक का प्रवाह उचित क्रम और स्थितियों में स्थापित करना पड़ता है।92. दहन अस्थिरता
दहन कक्ष में दबाव के खतरनाक दोलन इंजन को नुकसान पहुँचा सकते हैं। इसलिए दहन स्थिरता का व्यापक परीक्षण आवश्यक है।93. इंजन योग्यता परीक्षण
नई इंजन संरचना को परिचालन में लाने से पहले अपेक्षित परिस्थितियों में व्यापक योग्यता परीक्षण किए जाते हैं।94. योग्यता और स्वीकृति परीक्षण में अंतर
योग्यता परीक्षण किसी डिजाइन की क्षमता प्रमाणित करता है, जबकि स्वीकृति परीक्षण यह सुनिश्चित करता है कि वास्तविक उड़ान में प्रयुक्त विशेष इकाई निर्धारित मानकों को पूरा करती है।95. स्थिर प्रज्वलन परीक्षण
इस परीक्षण में इंजन को परीक्षण मंच पर स्थिर रखा जाता है और उसे चलाकर उसके प्रदर्शन को मापा जाता है।96. सेंसर और मापन
तापमान, दबाव, कंपन, प्रवाह दर, प्रणोद और अन्य मानकों को सेंसरों के माध्यम से मापा जाता है।97. परीक्षण से विश्वसनीयता
भूमि परीक्षण से उड़ान से पहले संभावित समस्याओं की पहचान संभव होती है, जिससे मिशन जोखिम कम किया जा सकता है।98. पेलोड अंश
प्रक्षेपण यान के कुल प्रारंभिक द्रव्यमान का अपेक्षाकृत छोटा भाग ही उपयोगी पेलोड होता है। इंजन दक्षता बढ़ाने से इसमें सुधार हो सकता है।99. रॉकेट समीकरण
रॉकेट प्रदर्शन निकास वेग और द्रव्यमान अनुपात से गहराई से प्रभावित होता है। इसी कारण उच्च विशिष्ट आवेग और बहु-चरणीय संरचना महत्वपूर्ण हैं।100. हर चरण में क्रायोजेनिक इंजन क्यों नहीं?
क्रायोजेनिक प्रणाली अत्यधिक दक्ष है, लेकिन जटिल भी है। बड़े ऊष्मा-रोधित टैंक और अत्यंत कम तापमान की व्यवस्था आवश्यक होती है। प्रारंभिक चरण में अन्य प्रणोदन प्रणालियाँ अधिक उपयुक्त हो सकती हैं।101. क्रायोजेनिक और अर्ध-क्रायोजेनिक प्रणोदन
क्रायोजेनिक प्रणोदन में सामान्यतः द्रव हाइड्रोजन और द्रव ऑक्सीजन का उपयोग होता है, जबकि अर्ध-क्रायोजेनिक प्रणाली में द्रव ऑक्सीजन के साथ परिष्कृत केरोसीन जैसे हाइड्रोकार्बन ईंधन का उपयोग किया जा सकता है।102. अर्ध-क्रायोजेनिक तकनीक का महत्व
इसमें ईंधन का घनत्व अधिक हो सकता है और मजबूत प्रणोद प्राप्त किया जा सकता है, इसलिए यह बूस्टर या कोर चरण के लिए उपयोगी हो सकती है।103. क्रायोजेनिक और हाइपरगोलिक प्रणोदक
हाइपरगोलिक ईंधन और ऑक्सीकारक संपर्क में आते ही स्वतः प्रज्वलित हो सकते हैं, जबकि क्रायोजेनिक प्रणोदकों को अत्यंत निम्न तापमान पर रखना पड़ता है और नियंत्रित प्रज्वलन आवश्यक होता है।104. हाइपरगोलिक प्रणोदकों का लाभ
जहाँ विश्वसनीय प्रज्वलन और पुनः प्रज्वलन आवश्यक हो, वहाँ ये उपयोगी हो सकते हैं।105. हाइपरगोलिक प्रणोदकों की सीमा
कई पारंपरिक हाइपरगोलिक प्रणोदक अत्यधिक विषैले और पर्यावरणीय दृष्टि से हानिकारक होते हैं।106. प्रणोदक घनत्व का महत्व
कम घनत्व वाले ईंधन के लिए समान द्रव्यमान रखने हेतु बड़े टैंक की आवश्यकता होती है, जिससे यान की संरचना प्रभावित होती है।107. हाइड्रोजन की विशेष चुनौती
द्रव हाइड्रोजन उच्च विशिष्ट आवेग देता है, लेकिन इसका घनत्व बहुत कम है। इसलिए अपेक्षाकृत बड़े टैंक आवश्यक होते हैं।108. बॉयल-ऑफ
क्रायोजेनिक टैंक में बाहरी ऊष्मा प्रवेश करने पर द्रव प्रणोदक वाष्प में बदल सकता है। इसे बॉयल-ऑफ कहा जाता है।109. टैंक दाब प्रणाली
दाब प्रणाली टैंक की संरचनात्मक स्थिरता और नियंत्रित प्रणोदक प्रवाह के लिए आवश्यक परिस्थितियाँ बनाए रखने में सहायता करती है।110. LTPM प्रदर्शन का महत्व
LTPM का सफल प्रदर्शन दर्शाता है कि विश्वसनीय प्रणोदन केवल मुख्य इंजन पर निर्भर नहीं करता; उससे जुड़ी द्रव और दाब प्रणालियाँ भी समान रूप से महत्वपूर्ण हैं।111. प्रणाली अभियांत्रिकी
सफल प्रक्षेपण के लिए प्रणोदन, संरचना, वैमानिकी, दिशा-निर्देशन, नियंत्रण, ताप सुरक्षा और भूमि प्रणालियों का सफल एकीकरण आवश्यक है।112. वैमानिकी
इसमें दिशा-निर्देशन, नौवहन, नियंत्रण, दूरमिति और यान प्रबंधन से संबंधित इलेक्ट्रॉनिक प्रणालियाँ शामिल हैं।113. दिशा-निर्देशन प्रणाली
यह प्रणाली निर्धारित करती है कि पेलोड को इच्छित कक्षा में पहुँचाने के लिए यान को किस पथ का अनुसरण करना चाहिए।114. नौवहन प्रणाली
यह उड़ान के दौरान यान की स्थिति, वेग और अभिविन्यास का अनुमान लगाती है।115. नियंत्रण प्रणाली
यह सुनिश्चित करती है कि प्रक्षेपण यान आवश्यक दिशा और प्रक्षेप पथ का अनुसरण करे।116. प्रणोद दिशा नियंत्रण
इंजन के प्रणोद की दिशा बदलकर रॉकेट की दिशा और अभिविन्यास नियंत्रित किए जा सकते हैं।117. पेलोड आवरण
यह आरोहण के दौरान उपग्रह को वायुगतिकीय बल और ताप से सुरक्षा प्रदान करता है।118. आवरण पृथक्करण
जब यान पर्याप्त ऊँचाई पर पहुँच जाता है और वायुमंडल बहुत विरल हो जाता है, तब पेलोड आवरण को अलग किया जा सकता है।119. अंतरिक्ष मलबा
आधुनिक प्रक्षेपण प्रणालियों को प्रयुक्त चरणों और कक्षीय मलबे के जिम्मेदार प्रबंधन पर भी ध्यान देना पड़ता है।120. अंतरिक्ष की दीर्घकालीन स्थिरता
विश्व में प्रक्षेपण गतिविधि बढ़ने के साथ बाह्य अंतरिक्ष के सुरक्षित और सतत उपयोग का महत्व बढ़ रहा है।121. अंतरिक्ष स्थितिजन्य जागरूकता
इसका अर्थ अंतरिक्ष में वस्तुओं की निगरानी और पर्यावरणीय परिस्थितियों की जानकारी रखना है ताकि टकराव तथा अन्य जोखिम कम किए जा सकें।122. भारत का व्यापक अंतरिक्ष पारितंत्र
भारत के अंतरिक्ष क्षेत्र में इसरो के साथ NewSpace India Limited, IN-SPACe, निजी कंपनियाँ, नवउद्यम और शैक्षणिक संस्थान भी महत्वपूर्ण भूमिका निभा रहे हैं।123. इसरो की भूमिका
इसरो भारत की राष्ट्रीय अंतरिक्ष एजेंसी है और अंतरिक्ष विभाग के अंतर्गत कार्य करती है।124. अंतरिक्ष विभाग
अंतरिक्ष विभाग भारत के राष्ट्रीय अंतरिक्ष कार्यक्रम से संबंधित प्रमुख विभाग है।125. IN-SPACe
Indian National Space Promotion and Authorization Centre भारत के अंतरिक्ष क्षेत्र में गैर-सरकारी संस्थाओं की भागीदारी को प्रोत्साहित और अधिकृत करता है।126. NSIL
NewSpace India Limited अंतरिक्ष विभाग के अंतर्गत केंद्रीय सार्वजनिक क्षेत्र का उद्यम है और अंतरिक्ष क्षमताओं के वाणिज्यीकरण में भूमिका निभाता है।127. अंतरिक्ष तकनीक और अर्थव्यवस्था
प्रक्षेपण क्षमता संचार, नौवहन, पृथ्वी अवलोकन, मौसम विज्ञान, आपदा प्रबंधन, राष्ट्रीय सुरक्षा और वाणिज्यिक सेवाओं का आधार है।128. पृथ्वी अवलोकन
उपग्रह आँकड़ों का उपयोग कृषि, वन, जल संसाधन, नगर नियोजन, आपदा आकलन और पर्यावरण निगरानी में किया जा सकता है।129. संचार उपग्रह
ये प्रसारण, दूरसंचार और संपर्क सेवाओं को सक्षम बनाते हैं।130. नौवहन उपग्रह
उपग्रह नौवहन परिवहन, मानचित्रण, संचार और अनेक आर्थिक गतिविधियों के लिए स्थिति, दिशा और समय संबंधी सेवाएँ प्रदान करता है।131. अंतरिक्ष और आपदा प्रबंधन
दूरसंवेदी उपग्रह चक्रवात, बाढ़, वनाग्नि, भूस्खलन और अन्य आपदाओं के बारे में महत्वपूर्ण जानकारी दे सकते हैं।132. राष्ट्रीय विकास में अंतरिक्ष
भारत के अंतरिक्ष कार्यक्रम ने वैज्ञानिक और रणनीतिक उद्देश्यों के साथ सामाजिक-आर्थिक विकास में अंतरिक्ष तकनीक के उपयोग पर भी बल दिया है।133. CE20 का महत्व केवल एक मिशन तक सीमित नहीं
सितंबर 2026 का परीक्षण LVM3 की क्षमता बढ़ाने और भारत की भारी प्रक्षेपण क्षमता मजबूत करने की व्यापक प्रक्रिया का हिस्सा है।134. इंजन उन्नयन
इंजन को अधिक प्रदर्शन स्तर पर संचालित करते समय तापीय, संरचनात्मक और दहन संबंधी सीमाओं की सुरक्षा सुनिश्चित करनी पड़ती है।135. अधिक प्रणोद के लिए परीक्षण क्यों?
प्रणोद बढ़ने से दबाव, तापमान, प्रवाह दर और यांत्रिक भार बदलते हैं। इसलिए परिचालन उपयोग से पहले व्यापक परीक्षण आवश्यक है।136. 22 टन परीक्षण का महत्व
सितंबर 2026 परीक्षण ने CE20 उड़ान इंजन को नियोजित 22 टन उन्नत प्रणोद स्तर पर सफलतापूर्वक प्रदर्शित किया।137. मिशन-विशिष्ट इंजन
यह केवल प्रयोगात्मक इंजन नहीं था; परीक्षण किया गया CE20 इंजन LVM3-M7 मिशन के लिए निर्धारित है।138. परीक्षण से उड़ान तक
सफल परीक्षण के बाद इंजन का पुनर्सज्जीकरण, उड़ान चरण में एकीकरण और अतिरिक्त जाँच की जाएगी।139. प्रारंभिक परीक्षा तथ्य: CE20 ठोस मोटर नहीं है
CE20 द्रव प्रणोदक वाला क्रायोजेनिक इंजन है। इसे LVM3 के बड़े ठोस बूस्टरों से भ्रमित नहीं करना चाहिए।140. प्रारंभिक परीक्षा तथ्य: CE20 वायु-श्वासी इंजन नहीं है
यह ईंधन और ऑक्सीकारक दोनों अपने साथ ले जाता है।141. प्रारंभिक परीक्षा तथ्य: LOX ऑक्सीकारक है
CE20 में द्रव हाइड्रोजन ईंधन है और द्रव ऑक्सीजन ऑक्सीकारक है।142. प्रारंभिक परीक्षा तथ्य: क्रायोजेनिक का अर्थ ठंडा दहन नहीं
यह शब्द प्रणोदकों के अत्यंत निम्न भंडारण तापमान को दर्शाता है। दहन का तापमान अत्यधिक होता है।143. प्रारंभिक परीक्षा तथ्य: भूस्थिर और भू-समकालिक
हर भूस्थिर उपग्रह भू-समकालिक होता है, लेकिन हर भू-समकालिक उपग्रह भूस्थिर नहीं होता।144. प्रारंभिक परीक्षा तथ्य: रॉकेट को वायुमंडलीय वायु की आवश्यकता नहीं
रॉकेट अपना ऑक्सीकारक स्वयं साथ ले जाता है और निर्वात में भी कार्य कर सकता है।145. प्रारंभिक परीक्षा तथ्य: IPRC का स्थान
CE20 परीक्षण से संबंधित इसरो प्रणोदन परिसर महेंद्रगिरि, तमिलनाडु में स्थित है।146. प्रारंभिक परीक्षा तथ्य: LVM3 का पुराना नाम
LVM3 को पहले GSLV Mk III कहा जाता था।147. प्रारंभिक परीक्षा तथ्य: मिशन संख्या
LVM3-M7, LVM3 का सातवाँ परिचालन मिशन है।148. प्रारंभिक परीक्षा तथ्य: परीक्षण और घोषणा की तिथि
परीक्षण 9 सितंबर 2026 को हुआ और इसरो ने इसकी सूचना 10 सितंबर 2026 को प्रकाशित की।149. प्रारंभिक परीक्षा तथ्य: मिशन का समय
LVM3-M7 को 2026 की चौथी तिमाही में निर्धारित किया गया है।150. प्रारंभिक परीक्षा तथ्य: NPS
इस संदर्भ में NPS का अर्थ Nozzle Protection System है।151. प्रारंभिक परीक्षा तथ्य: LTPM
LTPM का अर्थ LOX Tank Pressurization Module है।152. प्रारंभिक परीक्षा तथ्य: C32
C32 उस क्रायोजेनिक चरण संरचना से संबंधित है जिसमें भविष्य के LVM3 मिशनों के लिए उन्नत CE20 इंजन का उपयोग प्रस्तावित है।153. UPSC के लिए महत्व
यह विषय समसामयिकी के साथ क्रायोजेनिक प्रणोदन, रॉकेट चरण, कक्षीय यांत्रिकी, इसरो संस्थानों और गगनयान जैसे स्थिर विषयों को जोड़ता है।154. संभावित प्रारंभिक प्रश्न
CE20, LOX, LH2, LVM3, IPRC, गगनयान और क्रायोजेनिक प्रणोदन का मिलान पूछा जा सकता है।155. संभावित कथन-आधारित प्रश्न
प्रश्न यह जाँच सकता है कि क्या CE20 वातावरण से ऑक्सीजन लेता है, क्या हाइड्रोजन ऑक्सीकारक है या क्रायोजेनिक चरण ऊपरी चरण में उपयोग होता है।156. संभावित अवधारणात्मक प्रश्न
ऊपरी चरण के लिए क्रायोजेनिक प्रणोदन का मुख्य लाभ उच्च दक्षता और उच्च विशिष्ट आवेग है।157. संभावित स्थान प्रश्न
महेंद्रगिरि, तमिलनाडु को इसरो के प्रणोदन परीक्षण से जोड़कर याद रखना चाहिए।158. गगनयान संबंध
CE20 और C32 प्रणालियाँ मानव-अनुकूलित LVM3 और गगनयान की व्यापक प्रणोदन संरचना से जुड़ी हैं।159. भौतिकी संबंध
रॉकेट प्रणोदन संवेग संरक्षण और न्यूटन के तीसरे नियम पर आधारित है।160. अभियांत्रिकी संबंध
क्रायोजेनिक तकनीक के लिए निम्न तापमान भंडारण, टर्बोमशीनरी, दहन, पदार्थ विज्ञान, ऊष्मा-रोधन और नियंत्रण में विशेषज्ञता आवश्यक है।161. रणनीतिक संबंध
स्वदेशी प्रणोदन तकनीक महत्वपूर्ण प्रक्षेपण तकनीकों के लिए बाहरी निर्भरता कम करती है।162. आर्थिक संबंध
बेहतर भार वहन क्षमता भारत की वाणिज्यिक प्रक्षेपण क्षमता और बड़े घरेलू अंतरिक्ष मिशनों को मजबूत कर सकती है।163. विज्ञान नीति संबंध
उन्नत प्रणोदन में निवेश पदार्थ विज्ञान, विनिर्माण, परीक्षण, संगणकीय अभियांत्रिकी और नियंत्रण प्रणाली जैसे क्षेत्रों में व्यापक तकनीकी लाभ उत्पन्न करता है।164. त्वरित पुनरावृत्ति 1
CE20 इसरो का स्वदेशी क्रायोजेनिक इंजन है और LVM3 के ऊपरी चरण में उपयोग होता है।165. त्वरित पुनरावृत्ति 2
CE20 में द्रव हाइड्रोजन ईंधन और द्रव ऑक्सीजन ऑक्सीकारक है।166. त्वरित पुनरावृत्ति 3
नवीन उड़ान-स्वीकृति उष्ण परीक्षण 9 सितंबर 2026 को किया गया।167. त्वरित पुनरावृत्ति 4
परीक्षण IPRC, महेंद्रगिरि, तमिलनाडु में हुआ।168. त्वरित पुनरावृत्ति 5
परीक्षित CE20 इंजन LVM3-M7 मिशन के लिए निर्धारित है।169. त्वरित पुनरावृत्ति 6
LVM3-M7, LVM3 का सातवाँ परिचालन मिशन है।170. त्वरित पुनरावृत्ति 7
इंजन को उन्नत 22 टन प्रणोद स्तर पर सफलतापूर्वक परीक्षण किया गया।171. त्वरित पुनरावृत्ति 8
भविष्य के LVM3 मिशनों में C32 चरण को उन्नत CE20 प्रणोद स्तर के साथ संचालित करने की योजना है।172. त्वरित पुनरावृत्ति 9
NPS का पूर्ण रूप Nozzle Protection System है।173. त्वरित पुनरावृत्ति 10
LTPM का पूर्ण रूप LOX Tank Pressurization Module है।174. त्वरित पुनरावृत्ति 11
परीक्षण में प्रदर्शित LTPM गगनयान आवश्यकताओं से संबंधित C32 चरणों के लिए है।175. त्वरित पुनरावृत्ति 12
LVM3-M7 मिशन 2026 की चौथी तिमाही में निर्धारित है।176. निष्कर्ष
CE20 इंजन का सफल उड़ान-स्वीकृति परीक्षण भारत की स्वदेशी क्रायोजेनिक प्रणोदन क्षमता की निरंतर प्रगति को दर्शाता है। 22 टन के उन्नत प्रणोद स्तर पर इंजन का सफल संचालन भविष्य के LVM3 मिशनों की भार वहन क्षमता बढ़ाने की दिशा में महत्वपूर्ण कदम है। C32 चरण, गगनयान से संबंधित प्रणालियों और उन्नत परीक्षण तकनीकों के साथ CE20 कार्यक्रम भारत की भारी प्रक्षेपण क्षमता, मानव अंतरिक्ष उड़ान, वाणिज्यिक अंतरिक्ष सेवाओं और रणनीतिक तकनीकी आत्मनिर्भरता के लिए अत्यंत महत्वपूर्ण है।Attempt Quiz : UPSC 2027 Prelims Current Affairs Quiz: ISRO CE20 Cryogenic Engine,
